NetComm NF17ACV

www.netcommwireless.com
NetComm Wireless NF17ACV User Guide
47
v1.0
Policy Routing
This function allows you to add policy rules to certain situations.
Click the Add button to add a policy rule. The following screen is displayed.
Figure 8: Advanced - Routing - Add Policy Route
Enter the details into the provided fields. The table below describes each field.
FIELD
DESCRIPTION
Policy Name
A user defined name for the policy route.
Physical LAN Port
The LAN port to be used for the policy.
Source IP
The IP address of the LAN device involved with the policy.
Use Interface
Select the Interface that the policy will employ.
Default Gateway
Enter the gateway address.
