OPTION
DEFINITION
Line
Displays the phone port you want to configure
Call Waiting
Select this option for your phone if your VoIP Service Provider has enabled Call Waiting on your SIP account.
Unconditionally Call forwarding
number
Select this option if your VoIP Service Provider has enabled Call Forwarding on your SIP account and you wish
to use this feature.
Busy Call Forwarding Number
Enter the phone number to forward a call to if it arrives while the line is busy.
No Answer Call forwarding
number
Enter the phone number to forward a call to if the call is not answered.
Forward On “busy”
Select this option if your VoIP Service Provider has enabled Call Forwarding on your SIP account and you wish
to use this feature.
Forward On “No Answer”
Select this option if your VoIP Service Provider has enabled Call Forwarding on your SIP account and you wish
to use this feature.
MWI (Message Waiting
Indicator)
Select this option if your VoIP Service Provider has enabled MWI (Message Waiting Indicator) on your SIP
account and you wish to use this feature.
Anonymous Call Blocking
Select this option if your VoIP Service Provider has enabled Anonymous Call Blocking on your SIP account and
you wish to use this feature.
Anonymous Calling
Select this option if your VoIP Service Provider has enabled Anonymous Calling on your SIP account and you
wish to use this feature.
Anonymous calling mode
When set to Display anonymous, the modem hides your caller ID. When set to All anonymous, the modem
hides both caller ID and the SIP URL of the originating call.
DND (Do Not Disturb)
Select this option if your VoIP Service Provider has enabled DND (Do Not Disturb) on your SIP account and you
wish to use this feature.
Enable T38 Redundancy
Support
Select this function if you wish to send or receive faxes via VoIP and have a fax machine capable of using the
T38 fax over VoIP protocol.
Enable VBD redundancy
support
Select this checkbox to use the feature.
Enable VAD support
Enables the Voice Activated Detection function of the modem. When enabled, no data is transmitted during
periods of silence or low volume, reducing the data usage.
Enable RTCP Flow Control
Select this checkbox to use the feature.
Enable Echo Cancellation
Select this checkbox to use the feature.
Enable # To ASCII
Select this checkbox to use the feature.
Enable Reinjection Function
Select this checkbox to use the feature.
RFC2198 Payload Value
(range 97-127)
Enter the RFC2198 payload value that the valid range is 96 ~ 127.
Registration Expire Timeout
Enter the registration expire timeout.
Session Expire Time
The interval of dialog refreshing time.
Min Session Expire Time
The minimum interval of dialog refreshing time.
VoIP DialPlan Setting
Set the VoIP dial plan. If user-dialed number matches it, the number is processed by the VoIP router
immediately.
DSCP for SIP
Set the DSCP QoS tagging for Session Initiation Protocol. You can select it from the drop-down list.
DSCP for RTP
Set the DSCP QoS tagging for Real-time Transport Protocol. You can select it from the drop-down list.
Dtmf Relay Setting
Set DTMF transmit method, which can be following values:
– SIP Info: Use SIP INFO message to transmit DTMF digits.
– RFC2833: Use RTP packet to encapsulate DTMF events, as specified in RFC 2833.
– InBand: DTMF events are mixed with user voice in RTP packet.
SIP Transport Protocol
Select the transport protocol to use for SIP signaling. Note that your SIP proxy and registrar will need to
support the protocol you select.
Enable Local Supplementary
Service
Select the checkbox to enable the supplementary service settings by the telephone set. If you deselect the
checkbox, the supplementary service cannot be set by the telephone set.
Table 3: VoIP - Advanced - Service Provider
