CHAPTER
NINE
OPTIONAL M.2 SATA INSTALLATION
The Netgate® 2100 has built-in onboard eMMC storage. Optionally, a M.2 SATA drive could be installed as an
upgrade or to bypass the onboard eMMC flash memory.
Warning: Before proceeding:
1. Backup the configuration file, if possible.
2. Unplug the system for at least 60 seconds to ensure all phantom power has dissipated.
3. Anti-static protection must be used throughout this procedure.
4. Any hardware damage incurred during this procedure is not covered by the hardware warranty.
Note: pfSense
®
Plus software must be reinstalled on the M.2 SATA drive. By default, the M.2 SATA drive will then
be the first drive recognized by pfSense
®
Plus software.
Note: The Netgate 2100 does not support NVMe drives.
The Netgate 2100 has one slot capable of installing an optional M.2 SATA drive.
The connector is for a 2242 (22mm x 42mm) M.2 SATA only.
Warning: The 42mm standoff cannot be moved without disconnecting the thermal paste between the processor
and the heat sink. This is not supported and may void the warranty.
1. Turn the system over carefully to avoid scratching the top of the system. Remove the four (4) T10 Torx screws
as indicated below.
40
