Security Gateway Manual SG-2100

Fig. 1: Removing the Netgate 2100 Case Screws

2. Turn system upright and carefully remove the cover. Set the cover off to the side and keep it upright so the top

is not scratched. Identify where the M.2 SATA drive slot is located and remove the screw from the standoff.

Note: If the standoff turns while attempting to remove the screw, hold the standoff with a ﬁne pair of needle-

nosed pliers.

Fig. 2: M.2 SATA Location and Screw

3. After the screw has been removed, insert the M.2 SATA drive into the slot at about a 30° angle.
