Table 1. LED descriptions (Continued)
DescriptionIconLED
• Green. A powered-on device is connected to the LAN port at 1000
Mbps.
• Amber. A powered-on device is connected to the LAN port at 10 Mbps
or 100 Mbps.
• Off. No device is connected to the LAN port.
• Blinking green or amber.The LAN port is processing traffic.
LAN 1
• Green. A powered-on device is connected to the LAN port at 1000
Mbps.
• Amber. A powered-on device is connected to the LAN port at 10 Mbps
or 100 Mbps.
• Off. No device is connected to the LAN port.
• Blinking green or amber.The LAN port is processing traffic.
LAN 2
Rear Panel
The connections and button on the rear panel are shown in the following figure.
Hardware Setup
8
Nighthawk Multi-Gig Speed Cable Modem
