Wireless Cable Voice Gateway Model CVG834G Reference Manual
Managing Your Network 4-5
v2.0, November 2007
Running Diagnostic Utilities
You can use diagnostics to test connectivity to a PC with the ping command. From the main menu,
below the Maintenance heading, select Diagnostics. The Ping screen appears:
To perform a ping test:
1. In the Target field, enter the IP address of the PC that you want to ping.
2. If you want to specify additional details, you can set the Ping Size, No. of Pings, and the Ping
Interval.
3. Click Start Test to begin the test. Test results are displayed on this screen.
• To stop a test in progress, click Abort Test.
• To delete the results of a ping test from the Results display, click Clear Results.
• To update the results of a ping test, click REFRESH.
Setup Features
Setup features include viewing the MTA status, guest network, and Wi-Fi Multimedia (WMM).
Figure 4-4
