Reference Manual for the ADSL Modem Wireless Router DG834G
Virtual Private Networking 8-31
v1.3, March 2007
Figure 8-31: Running a Ping test to the LAN from the PC
This will cause a continuous ping to be sent to the first DG834G v3. After between several
seconds and two minutes, the ping response should change from “timed out” to “reply.”
Once the connection is established, you can open the browser of the PC and enter the LAN IP
address of the remote DG834G v3. After a short wait, you should see the login screen of the
Modem Router (unless another PC already has the DG834G v3 management interface open).
• Gateway-to-Gateway Configuration—test the VPN tunnel by pinging the remote network
from a PC attached to the DG834G v3.
a. Open command prompt (i.e., Start -> Run -> cmd).
Note: Use Ctrl-C to stop the pinging.
Figure 8-32
