Reference Manual for the ADSL Modem Wireless Router DG834G
Configuring Your Internet Connection 3-5
v1.3, March 2007
b. Two-Line Filter Example. Insert the two-line filter into the phone outlet and connect the
phone to the phone line connector (A):
Figure 3-6
Note: To use a one-line filter with a separate splitter, insert the splitter into the
phone outlet, connect the one-line filter to the splitter, and connect the
phone to the filter.
Phone
DSL
Line
A
