NETGEAR DG834N

DG834N RangeMax NEXT Wireless ADSL2+ Modem Router Reference Manual
Managing Your Network 4-9
v1.0, April 2008
Click the Connection Status button to display modem router connection status, as shown in the
following screen.
This screen shows the following statistics:
Figure 4-5
Table 4-3. Connection Status Fields (PPPoE Network Type Example)
Field Description
Connection Time The time elapsed since the last connection to the Internet through the ADSL port.
Connecting to
sender
The connection status.
Negotiation Success or Failed.
Authentication Success or Failed.
Obtaining IP
Address
The IP address assigned to the WAN port by the ADSL Internet Service Provider.
Obtaining Network
Mask
The network mask assigned to the WAN port by the ADSL Internet Service Provider.
