NETGEAR DGN1000 - Wireless-N Router With Built-in DSL Modem User Manual

Installing Your Router Manually (Advanced, Mac, and Linux Users) 14
• Two-Line Filter Example. Insert the two-line filter into the phone outlet and connect the
phone to the phone line connector (A), as shown in Figure 7.
2. Connect the wireless modem router to the ADSL filter. Using the included phone cable with
RJ-11 jacks, connect the ADSL port (B) of the wireless modem router to the ADSL port (C) of
the two-line filter, as shown in Figure 8.
Figure 7
To use a one-line filter with a separate splitter, insert the splitter into the phone
outlet, connect the one-line filter to the splitter, and connect the phone to the
filter.
A

NETGEAR DGN1000 - Wireless-N Router With Built-in DSL Modem Specifications

General

Brand	NETGEAR
Model	DGN1000
Type	Wireless-N Router With Built-in DSL Modem
Wireless Standard	802.11b/g/n
Frequency Band	2.4 GHz
Wireless Speed	Up to 150 Mbps
DSL Modem	Yes
USB Ports	No
Ethernet Ports	4 x 10/100 Mbps
DSL Standards	ADSL/ADSL2/ADSL2+
Security	WEP, WPA-PSK, WPA2-PSK
Firewall	NAT firewall
Weight	0.29 kg (0.64 lb)
