NETGEAR DGN1000 - Wireless-N Router With Built-in DSL Modem User Manual

Installing Your Router Manually (Advanced, Mac, and Linux Users) 15
.
3. Connect the Ethernet cable (D) from a wireless modem router LAN port to the Ethernet
adapter in your computer, as shown in Figure 9.
4. Connect the power adapter to the wireless modem router and plug it in to a power outlet.
Figure 8
Improperly connecting a filter to your wireless modem router will block
your ADSL connection.
C
B

NETGEAR DGN1000 - Wireless-N Router With Built-in DSL Modem Specifications

General

Brand	NETGEAR
Model	DGN1000
Type	Wireless-N Router With Built-in DSL Modem
Wireless Standard	802.11b/g/n
Frequency Band	2.4 GHz
Wireless Speed	Up to 150 Mbps
DSL Modem	Yes
USB Ports	No
Ethernet Ports	4 x 10/100 Mbps
DSL Standards	ADSL/ADSL2/ADSL2+
Security	WEP, WPA-PSK, WPA2-PSK
Firewall	NAT firewall
Weight	0.29 kg (0.64 lb)
