NETGEAR EX3110 User Manual

5. Select Do More > Access Schedule.
The Access Schedule pahe displays.
6. Select the Access Schedule On radio button.
The page adjusts.
7. In the Days menu and the Time menu, select the day and time when you want to disable Internet access.
8. Click the Add Time button to add the time that you specified to the Scheduled Times table.
9. Click the SAVE button.
Your settings are saved.
Change the Extender’s Device Name
The default name is EX3800.
To change the extender’s device name:
1. Launch a web browser from a computer or mobile device that is connected to your extender network.
2. Log in to your extender:
• If your extender and router use different WiFi network names (SSIDs), enter www.mywifiext.net.
• If your extender and router use the same WiFi network name (SSID), enter http://<extender’s IP
address> (for example, http://192.168.1.3).
For more information about how to find your extender's IP address, see Find Extender's IP Address
on page 40.
A login page displays.
3. Enter your admin email and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Settings > Wireless Settings.
The WiFi Settings page displays.
6. Scroll down and click the IP Address heading.
The page expands.
7. In the Device Name field, type a name.
8. Click the SAVE button.
Your settings are saved.
Extender Network Settings
24
AC750 WiFi Range Extender

NETGEAR EX3110 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	750 Mbit/s
Product color	White

Weight and Dimensions

Width	72.5 mm
Height	64.8 mm
Weight	152 g
