FS728TP Smart Switch FS728TP Smart Switch Software Administration Manual
Managing Security 6-19
v1.0, December 2007
To add a new MAC-based ACL entry:
1. Click Security > ACL > MAC ACL. The MAC Configuration screen displays.
2. Enter the ACL Name in the provided field in the first row.
3. Click Add to update the device.
To remove a MAC-based ACL entry:
1. Click Security > ACL > MAC ACL. The MAC Configuration screen displays.
2. Select the ACL entry.
3. Click Delete to remove the entry.
MAC Rules
The MAC Rules screen allows a MAC Rule to be defined within a configured ACL. Rules can be
added only if the ACL is not bound to an interface.
To define MAC Rules:
1. Click Security > ACL > MAC Rules. The MAC Rules screen displays:
The MAC Rules screen contains the following fields:
MAC ACL
• ACL Name – Select the ACL Name from the list.
Rule Table
Figure 6-11
