NETGEAR GS108Tv3 User Manual

8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure Switching User Manual162
8. In the VLAN ID field, specify a VLAN ID in the range from 1 to 4093.
9. Click the Delete button.
The MAC address is removed from the VLAN mapping.
Configure protocol-based VLAN groups
You can use a protocol-based VLAN to define filtering criteria for untagged packets. By
default, if you do not configure any port-based (IEEE 802.1Q) or protocol-based VLANs,
untagged packets are assigned to VLAN 1. You can override this behavior by defining either
port-based VLANs or protocol-based VLANs, or both. Tagged packets are always handled
according to the IEEE 802.1Q standard and are not included in protocol-based VLANs.
If you assign a port to a protocol-based VLAN for a specific protocol, untagged frames that
arrive on that port for that protocol are assigned the protocol-based VLAN ID. Untagged
frames that arrive on the port for other protocols are assigned the port VLAN ID, either the
default PVID (1) or a PVID you specifically assigned to the port (see
Configure the PVID
settings for an interface on page 157).
You define a protocol-based VLAN by creating a group. Each group forms a one-to-one
relationship with a VLAN ID, can include one to three protocol definitions, and can include
multiple ports. When you create a group, you specify a name and a group ID is assigned
automatically.
To configure a protocol-based VLAN group:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the switch on-network and
connected to the Internet on page 19 or Access the switch off-network on page 30.
The login page displays.
If the NETGEAR Business page displays, see Register and access the switch with your
NETGEAR account on page 34.
4. Enter one of the following passwords:
• After registration, enter the local device password.
By default, the local device password is password.
• If you previously managed the switch through the Insight app or Cloud portal, enter
the Insight network password for the last Insight network location.
For information about the credentials, see Credentials for the local browser interface on
page 32.

NETGEAR GS108Tv3 Specifications

General

Multicast support	Yes
IPv4 multicast entries	32
Number of multicast groups filtered	256
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet, Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS
Power connector	DC-in jack
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	No
Certification	CE, FCC, VCCI Class B, C-Tick
Product color	Gray
LED indicators	Activity, LAN, Link, PoE, Power, Speed
Number of VLANs	64
Networking standards	IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-TX
Memory type	RAM
Flash memory	32 MB
Internal memory	128 MB
Processor frequency	500 MHz
Mean time between failures (MTBF)	2388657 h
MAC address table	8000 entries
Packet buffer memory	0.5 MB
Heat dissipation	18.66 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
DHCP features	DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) IPv6 entries	100
Input current	1.25 A
AC input voltage	100 - 240 V
DC input voltage	54 V
AC input frequency	50 - 60 Hz
Power consumption (max)	5.5 W
Package type	Box
Package depth	270 mm
Package width	226 mm
Package height	64 mm
Package weight	780 g
Master (outer) case width	214 mm
Master (outer) case height	312 mm
Master (outer) case length	474 mm
Master (outer) case weight	5490 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	6 pc(s)

Weight and Dimensions

Depth	101 mm
Width	158 mm
Height	27 mm
Weight	43000 g
