NETGEAR GS108Tv3 User Manual

8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure System Information User Manual91
light. Transition to low power mode does not change the link status. Frames in transit are
not dropped or corrupted in transition to and from low power mode. Transition time is
transparent to upper layer protocols and applications.
10. Click the Apply button.
Your settings are saved.
Use the Device View
For information about the device view, see Use the Device View of the local browser
interface on page 40.
Configure Power over Ethernet
For models GS110TPv3 and GS110TPP, you can configure the global Power over Ethernet
(PoE) configuration settings and the PoE settings for each port.
Note: For more information about PoE, see the hardware installation guide,
which you can download by visiting netgear.com/support/download/.
PoE concepts
Models GS110TPv3 and GS110TPP include eight PoE plus (PoE+) ports.
The following table shows the capacity for each model.
Table 19. PoE capacities for models GS110TPv3 and GS110TPP
Model Maximum PoE Power
Per Individual Port
Maximum Power Budget Across
All Active PoE+ Ports
GS110TPv3 30W PoE+ (IEEE 802.3at) 55W
GS110TPP 30W PoE+ (IEEE 802.3at) 120W.
By default, supplied power is prioritized in ascending port order, up to the total power budget
of the device. If the power requirements for the attached devices exceed the total power
budget of the switch, the power to the device on the highest-numbered PoE+ port is disabled
Note: By purchasing and connecting the
NETGEAR optional power adapter model
EPS200W, you can upgrade the PoE
power budget to 190W.

NETGEAR GS108Tv3 Specifications

General

Multicast support	Yes
IPv4 multicast entries	32
Number of multicast groups filtered	256
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet, Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS
Power connector	DC-in jack
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	No
Certification	CE, FCC, VCCI Class B, C-Tick
Product color	Gray
LED indicators	Activity, LAN, Link, PoE, Power, Speed
Number of VLANs	64
Networking standards	IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-TX
Memory type	RAM
Flash memory	32 MB
Internal memory	128 MB
Processor frequency	500 MHz
Mean time between failures (MTBF)	2388657 h
MAC address table	8000 entries
Packet buffer memory	0.5 MB
Heat dissipation	18.66 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
DHCP features	DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) IPv6 entries	100
Input current	1.25 A
AC input voltage	100 - 240 V
DC input voltage	54 V
AC input frequency	50 - 60 Hz
Power consumption (max)	5.5 W
Package type	Box
Package depth	270 mm
Package width	226 mm
Package height	64 mm
Package weight	780 g
Master (outer) case width	214 mm
Master (outer) case height	312 mm
Master (outer) case length	474 mm
Master (outer) case weight	5490 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	6 pc(s)

Weight and Dimensions

Depth	101 mm
Width	158 mm
Height	27 mm
Weight	43000 g
