NETGEAR GS108Tv3 User Manual

8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure Routing User Manual237
Routing concepts
The switch supports IP routing. When a packet enters the switch, the switch checks the
destination MAC address to determine if it matches any of the configured routing interfaces.
If it does, the switch searches the host table for a matching destination IP address. If a
matching entry is found, the packet is routed to the host. If no matching entry is found, the
switch performs a longest prefix match on the destination IP address. If a matching entry is
found, the packet is routed to the next hop. If no matching entry is found, the packet is routed
to the next hop that is specified in the default route. If no default route exists, the packet is are
dropped.
The routing table can include static entries that you added manually. The host table can
include static entries that were manually added and entries that were dynamically added
through ARP.
Configure the routing mode
For information about how to configure the routing mode and display IP routing data, see the
following sections:
• Configure the router settings on page 237
• View the IP routing statistics on page 239
Configure the router settings
You can enable routing and configure the routing settings for the switch.
The switch allows routing through any of its interfaces only after you enable routing on the
switch. Separately, you can enable routing on VLANs (see
Configure VLAN routing on
page 243).
To enable routing on the switch:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the switch on-network and
connected to the Internet on page 19 or Access the switch off-network on page 30.
The login page displays.

NETGEAR GS108Tv3 Specifications

General

Multicast support	Yes
IPv4 multicast entries	32
Number of multicast groups filtered	256
Switch type	Managed
Switch layer	L2
Data link protocols	Ethernet, Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS
Power connector	DC-in jack
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	No
Certification	CE, FCC, VCCI Class B, C-Tick
Product color	Gray
LED indicators	Activity, LAN, Link, PoE, Power, Speed
Number of VLANs	64
Networking standards	IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-TX
Memory type	RAM
Flash memory	32 MB
Internal memory	128 MB
Processor frequency	500 MHz
Mean time between failures (MTBF)	2388657 h
MAC address table	8000 entries
Packet buffer memory	0.5 MB
Heat dissipation	18.66 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
DHCP features	DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) IPv6 entries	100
Input current	1.25 A
AC input voltage	100 - 240 V
DC input voltage	54 V
AC input frequency	50 - 60 Hz
Power consumption (max)	5.5 W
Package type	Box
Package depth	270 mm
Package width	226 mm
Package height	64 mm
Package weight	780 g
Master (outer) case width	214 mm
Master (outer) case height	312 mm
Master (outer) case length	474 mm
Master (outer) case weight	5490 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	6 pc(s)

Weight and Dimensions

Depth	101 mm
Width	158 mm
Height	27 mm
Weight	43000 g
