Status LEDs
Status LEDs are located on the front panel of the switch. Each port provides a left LED
and a right LED that, in combination, indicate speed and activity.
Table 2. LED descriptions
DescriptionRight
LED
Left
LED
LED
Off. No power is supplied to the switch.
Solid green. Power is supplied to the switch and the switch is ready
for operation.
N/A (single LED
only)
Power LED
Both LEDs solid green. A 1G link with a powered-on device is
detected.
Both LEDs blinking green. Traffic is detected on the 1G link.
GreenGreenPort LEDs for ports
1 through 8
Left LED solid green, right LED off. A 100M link with a powered-on
device is detected.
Left LED blinking green, right LED off. Traffic is detected on the
100M link.
OffGreen
Left LED off, right LED solid green. A 10M link with a powered-on
device is detected.
Left LED off, right LED blinking green. Traffic is detected on the
10M link.
GreenOff
No link with a powered-on device is detected.OffOff
User Manual9Hardware Overview of the
Switch
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS110EMX
