NETGEAR GS308T Hardware Installation Guide

Desktop switching
You can use either model GS308T or model GS310TP as a desktop switch to build a
small network that provides up to 1 Gbps access to desktop computers, non-PoE
surveillance cameras, a NAS, servers such as a file server, an IPTV, and so on. In a small
network such as a small office or home office network, connect the switch to a router
that, in turn, is connected to an Internet modem.
With 1 Gbps connections, the switch always functions in full-duplex mode. Any switch
port that is connected to a computer or file server can provide up to 2 Gbps bidirectional
throughput.
You must connect one LAN port on the switch (for example, port 8 in the following
figure) to a LAN port on the router. For model GS310TP, you can also make a 1 Gbps
fiber connection to a router that supports fiber and that is connected to the Internet.
Figure 5. Sample desktop switching with model GS308T
PoE overview (model GS310TP)
Model GS310TP supports eight Power over Ethernet plus (PoE+) ports. The switch can
supply up to 30W PoE+ (IEEE 802.3at) to each port up to its total maximum PoE power
budget of 55W across all active PoE+ ports. The switch is also compatible with PoE (IEEE
802.3af).
Supplied power is prioritized according to the port order, up to the total power budget
of the device. Port 1 receives the highest PoE priority, while port 8 is relegated to the
lowest PoE priority.
Hardware Installation Guide19Applications
S350 Series 8-Port Gigabit Ethernet Smart Managed Pro Switch

NETGEAR GS308T Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Master (outer) case width	214 mm
Master (outer) case height	312 mm
Master (outer) case length	474 mm
Master (outer) case weight	6110 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	6 pc(s)
Package type	Box
Package depth	270 mm
Package width	226 mm
Package height	64 mm
Package weight	750 g
Cables included	AC
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	No
Product color	Black
LED indicators	Activity, Link, Power
Country of origin	China
10G support	-
Multicast protocols	IGMP
Input current	1 A
DC input voltage	12 V
MAC address table	- entries
