10G LAN SFP+ port. One 10G LAN SFP+ port to connect an SFP+ module.
•
Power On/Off button. Press the Power On/Off button to provide power to the
router.
•
DC power connector. Connect the power adapter that came in the product package
to the DC power connector.
Position the Antennas
We recommend that you position the router antennas as shown in the following figure.
Figure 4. Position the antennas
User Manual16Hardware Setup
Nighthawk AD7200 Gaming Router Model XR700
