NETGEAR NIGHTHAWK R7000 User Manual

Optimize Performance
45
Nighthawk AC1900 Smart WiFi Router Model R7000
Your changes are saved.
Delete an Upstream QoS Policy
 To delete a QoS policy:
1. Launch an Internet browser from a computer or wireless device that is connected to the
network.
2. T
ype http://www.routerlogin.net or http://www.routerlogin.com.
A login screen displays.
3. Enter the router user name and password.
The user name is admin.
The default password is password. The user name and
password are case-sensitive.
The BASIC Home screen displays.
4. Select ADV
ANCED > Setup > QoS Setup > Upstream QoS.
5. Click the Setup QoS Rule button.
6. Select the radio button for the QoS policy
.
7. Click the Delete button.
The QoS Policy is removed from the list.
Optimize Video Streaming with Downstream QoS
Downstream Quality of Service (QoS) assigns high priority to Internet video streaming from
websites like YouTube and Netflix.
Best eort trac
Internet
High priority trac
Figure 8. Downstream QoS assigns high priority to video streaming from the Internet

NETGEAR NIGHTHAWK R7000 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC1900 (600 + 1300 Mbps)
WiFi Range	Very large homes
Processor	1GHz Dual Core
Antenna	3 external antennas
Beamforming	Yes
RAM	256MB
Flash Memory	128MB
Dimensions	11.22 x 7.26 x 1.97 in (285 x 184.5 x 50 mm)
Ethernet Ports	5 x 10/100/1000 Mbps Gigabit Ethernet ports (1 WAN & 4 LAN)
USB Ports	1 x USB 3.0, 1 x USB 2.0
Security	WPA2
Weight	1.65 lb (0.75 kg)
