The satellite status displays. The page displays information about the satellite
connections, hardware and firmware versions, and the WiFi networks in the 2.4 GHz
and 5 GHz bands.
8.
To view detailed information about devices that are connected to the satellite
networks, select Connected Devices.
The Connected Devices page displays. For each device, the page displays the IP
address, device name, MAC address, and connection type.
View and manage logs of router activity
The log is a detailed record of the websites users accessed or attempted to access and
many other router actions. You can specify which actions are logged. Up to 256 entries
can be stored in the log.
To view and manage logs:
1.
Launch a web browser from a computer or mobile device that is connected to your
Orbi network.
2. Enter orbilogin.com.
A login window displays.
If your browser does not display a login window but displays a security warning and
does not let you proceed, see Resolve a browser security warning on page 28.
3. Enter the admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Administration > Logs.
The Logs page displays the following information:
•
Date and time: The date and time the log entry was recorded.
•
Source IP: The IP address of the initiating device for this log entry.
•
Target address: The name or IP address of the website or news group visited
or to which access was attempted.
•
Action: The action that occurred, such as whether Internet access was blocked
or allowed.
User Manual150Manage and Monitor Your Orbi
Pro System
Orbi Pro WiFi 6 Router Model SXR80 and Orbi Pro WiFi 6 Satellite Model SXR80
