12
WiFi Bridge Setup
Use the Ethernet ports on your personal router to connect up to two
Ethernet-enabled devices wirelessly to your existing WiFi network.
NETGEAR
LAN
Internet/LAN
Reset
USB
WiFi
USB
Power
Internet
Existing
WiFi router
(Optional) Connect a USB device to the USB port
ļ To use the personal router as a WiFi bridge:
1. Connect an Ethernet cable between the LAN port of the personal
router and the Ethernet port of an Ethernet-enabled device.
2. (Optional) Connect an Ethernet cable between the Internet/LAN
port of the personal router and the Ethernet port of another device.
3. Connect the personal router to a power source.
For more information, see Power Inputs on page 5.
4. Turn on power to the personal router by moving the Internet Mode
switch from the Power Off position to the Wireless position.
