NETGEAR RAX120 User Manual

Top Panel LEDs and Buttons
The status LEDs and two buttons are located on the top panel of the router.
Figure 2. Top view
Table 1. LED descriptions
DescriptionLED and Button
Solid white. The router is ready.
Blinking white. The router is not ready, firmware is upgrading, or the Reset
button was pressed.
Off. Power is not supplied to the router.
Power LED
Solid white. The Internet connection is ready.
Blinking white. The port is sending or receiving traffic.
Off. No Ethernet cable is connected between the router and the modem.
Internet LED
User Manual11Hardware Setup
Nighthawk AX12 12-Steam AX6000 WiFi Router

NETGEAR RAX120 Specifications

General

WiFi Standard	802.11ax
WiFi Range	Very large homes
Processor	1.8GHz Quad-Core
MU-MIMO	Yes
Beamforming	Yes
USB Ports	2 x USB 3.0
Memory	512MB NAND Flash and 1GB RAM
WiFi Technology	Dual-Band WiFi 6 (802.11ax)
Antennas	8 high-performance internal antennas
