User Manual for the NETGEAR 54 Mbps Wireless PC Card WG511 v2
Preparing Your PCs for Network Access C-9
June 2005
DHCP Configuration of TCP/IP in Windows 2000
After you install a network card, TCP/IP for Windows 2000 is configured and set to DHCP
without your having to configure it. However, if there are problems, following the steps below to
configure TCP/IP with DHCP for Windows 2000.
Click on the My Network Places icon on the Windows desktop. This will bring up a window
called Network and Dial-up Connections.
• Right click on Local Area Connection and select Properties.
The Local Area Connection Properties
dialog box appears. Verify that you have
the correct Ethernet card selected in the
Connect using: box and that the
following two items are displayed and
selected in the box of “Components
checked are used by this connection:”
• Client for Microsoft Networks and
• Internet Protocol (TCP/IP)
Click OK.
