Reference Manual for the 108 Mbps Wireless Firewall Router WGT624 v3
Content Filtering 4-7
202-10090-01, April 2005
Figure 4-6: Logs menu
Log entries are described in Table 4-1
Table 4-1. Log entry descriptions
Field Description
Number The index number of the content filter log entries. 128 entries
are available numbered from 0 to 127. The log will keep the
record of the latest 128 entries.
Date and Time The date and time the log entry was recorded.
Source IP The IP address of the initiating device for this log entry.
Action This field displays whether the access was blocked or allowed.
The name or IP address of the website or newsgroup visited or
attempted to access.
