NETGEAR WGT624 User Manual

Maintenance 5-1
202-10090-01, April 2005
Chapter 5
Maintenance
This chapter describes how to use the maintenance features of your WGT624 v3 108 Mbps
Wireless Firewall Router. These features can be found by clicking on the Maintenance heading in
the Main Menu of the browser interface.
Viewing Wireless Router Status Information
The Router Status menu provides a limited amount of status and usage information. From the
Main Menu of the browser interface, click on Maintenance, then select System Status to view the
System Status screen, shown below.
Figure 5-1: Router Status screen

NETGEAR WGT624 Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Port	1 x 10/100 Mbps
Standards	IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u
Wireless Data Rates	Up to 54 Mbps
Security	WPA, WEP
Firewall	SPI Firewall
Weight	270 g
