NETGEAR WNCE2001 - Ethernet to Wireless Adapter

Chapter 1. Getting Started | 4
1
1. Getting Started
Hardware Features
Top Panel with LEDs
Top Panel LED Activity
Power • Solid green: Unit is powered on and operating
normally.
• Solid or blinking amber: Unit is busy.
• Solid red:yy Power source does not provide enough
power.
• Off: Unit is not powered on.
LAN • On: The Ethernet cable is connected.
• Off: No Ethernet cable is connected.
WLAN
• Green: The connection to the router is excellent.
• Amber: The connection to the router is good.
• Red: The connection to the router is poor.
• Off: No wireless connection.
Rear Panel
Ethernet port Power
Reset
WPS
button
button
Figure 1. Rear panel
