NETGEAR WNDR3800 User Manual

Genie Basic Settings
26
N600 Wireless Dual Band Gigabit Router Premium Edition WNDR3800
This screen displays the following:
• Basic.The Basic feature allows you to manage files and folders on a USB storage device
that is connected to the USB port of the router.
• ReadySHARE Cloud. ReadySHARE Cloud gives you remote access over the Internet to
a USB storage device that is connected to your router’s USB port.
• ReadySHARE Printerer. ReadySHARE Printer lets you connect a USB printer to the
router’s USB port, and access it wirelessly.
• Network/Device Name. The default is \\readyshare. This is the name used to access the
USB device connected to the router.
• Available Network Folders. The folders on the USB device.
Share Name. If only one device is connected, the default share name is USB_Storage.
You can click the name shown or you can type it in the address field of your Web browser.
If Not Shared is shown, the default share has been deleted and no other share for the
root folder exists. Click the link to change this setting.
Read/Write Access. Shows the permissions and access controls on the network folder:
All – no password (the default) allows all users to access the network folder. The user
name (account name) for All – no password is guest. The password for admin is the
same one that you use to log in to the router. By default, it is password.
Folder Name. Full path used by the network folder.
Volume Name. Volume name from the storage device (either USB drive or HDD).
Total/Free Space. Shows the current utilization of the storage device.
• Edit. Click the Edit button to edit the Available Network Folders settings.
• Safely Remove a USB Device. Click to safely remove the USB device attached to your
router.
You can click Refresh to update this screen.
For more information about USB storage, see Chapter 5, USB Storage.
Basic Wireless Settings
The Wireless Settings screen lets you view or configure the wireless network setup.
The WNDR3800 router comes with preset security. This means that the Wi-Fi network name
(SSID), network key (password), and security option (encryption protocol) are preset in the
factory. You can find the preset SSID and password on the bottom of the unit.
Note: The preset SSID and password are uniquely generated for every
device to protect and maximize your wireless security.

NETGEAR WNDR3800 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	802.11a, 802.11b, 802.11g
Channels quantity	2 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	5 GHz
Interface	USB
Weight (imperial)	1.2 lbs
Dimensions (WxDxH)	223 x 153 x 31 mm
USB ports quantity	1
Minimum system requirements	Internet Explorer 5.0, Firefox 2.0, Safari 1.4
Compatible operating systems	- Windows 7, Vista, XP, 2000 - Mac OS - UNIX - Linux
Dimensions (W x D x H) (imperial)	8.8 x 6 x 1.2 \
DHCP client	-
Supported network protocols	IPv6
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Authentication method	WEP, WPA, WPA2
Ethernet LAN (RJ-45) ports	5
Flash memory	16 MB
Certification	RoHS
Internal memory	128 MB
Cables included	LAN (RJ-45)
Product color	Black

Weight and Dimensions

Weight	5000 g
