NETGEAR XAV5601 User Manual

19
3
3. Troubleshooting
Basic Functioning
After you plug in the Powerline adapter, the following sequence of events should occur:
1. The Power LED lights up.
2. After approximately 10 seconds, verify that:
a. The Power LED is solid green.
b. The Powerline LED is lit.
c. The Ethernet LED lights or blinks.
Troubleshooting Tips
The Reset and Security buttons are located on the side panel of the adapter.
• Pressing the Reset button longer than 2 seconds does not reset the device.
• Pressing the Security button longer than 2 seconds does not activate security.
LEDs
The LEDs indicate activity, and can be used for troubleshooting.
LEDs Are Off When the Adapter Is Plugged In
• First check to make sure that the electrical outlet has power.
• If power is supplied and the LEDs stay off, someone might have used the Powerline
Utility to turn off the LEDs. Use the Powerline Utility to see if that is the case. If so, then
use the Powerline Utility to turn them back on.
Power LED
• Off. Make sure that power is supplied to the electrical outlet, and that the Powerline
devices are not plugged into an extension cord, power strip, or surge protector.
• Amber. Power saving mode occurs when the Ethernet LED is off. This can occur when:

NETGEAR XAV5601 Specifications

General

Data and routing protocols	IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx) IEEE 802.3ab (1000BaseTx)
Security encryption type	128-bit AES
MAC addresses	64: number of nodes that can be added to a single network
Frequency band:	2 –80Mbps
Modulation type:	OFDM symbol modulation
AC input	100–125V~, 0.2A max in North America and 200–250V~, 0.2A max in other regions
Power consumption	Normal: 4.5W, Power saving mode: <0.5W
Operating temperature	0 to 40 C (32º to 104º F)
Operating humidity	10–90% maximum relative humidity, noncondensing
Storage humidity	5–95% maximum relative humidity, noncondensing
Electromagnetic emissions:	FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals:	UL Listed (UL 60950-1:2nd Ed.) /cUL (CSA C22.2 No.60950-1-07 2nd Ed.); CE LVD; TUV CB, TUV GS
Bandwidth	5 00Mbps
Data transfer rate	U p to 200M bps with real throughput greater than 80Mbps
Compatibility	Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible

Weight and Dimensions

Dimensions	114 x 55 x 32.5 mm (4.5 x 2.2 x 1.28 in.)
Weight	0.174 kg (0.38 lb)
