NETGEAR XAV5601 User Manual

Getting Started
9
Powerline AV+ 500 Nano XAV5601
• To return the Powerline Adapter to its factory default settings, press its Factory Reset
button for 1 second, then release.
Use the Security Button to Set the Encryption Key
Note: An adapter can generate a private key only once. If you want to
replace a private key, first reset the adapters to their factory settings.
To do this either press the Reset button for 1 second, then release;
or use the Powerline Utility factory defaults feature (see
Reset a
Device to Factory Settings on page 15).
You can use the security button to change the default encryption key and set a private
encryption key instead. The default encryption key is HomePlugAV.
 To set the encryption key with the Security button:
1. Verify that all the Powerline adapters to be configured are plugged in.
CAUTION:
Do not press the Security button on the Powerline adapter until
installation is complete and all adapters on your network are plugged in
and communicating with each other. Pressing the Security button too soon
can temporarily disable Powerline communication. If this should occur,
reset the Powerline adapter to its factory default settings (press the Reset
button for 1 second, then release).
2. Press the Powerline Adapter Security button for 2 seconds.
• The Power LED starts blinking after you release the button.
• The adapter automatically creates a new, randomly generated network encryption key
that each Powerline adapter on the network will use.
At this point, the other adapters in your network cannot communicate with each other.
3. Within 2 minutes of pressing the Security button on the Powerline Adapter, press the
security button on the second adapter for 2 seconds.
In order to pair the devices, you need to press both buttons within 2 minutes.
This securely configures your Powerline network with the same network encryption key.
4. If your network has more than two adapters, press the Security button on the next adapter
for 2 seconds, then push the Security button on any additional adapters in your network for
2 seconds. The adapters retain security settings even if they are unplugged.

NETGEAR XAV5601 Specifications

General

Data and routing protocols	IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx) IEEE 802.3ab (1000BaseTx)
Security encryption type	128-bit AES
MAC addresses	64: number of nodes that can be added to a single network
Frequency band:	2 –80Mbps
Modulation type:	OFDM symbol modulation
AC input	100–125V~, 0.2A max in North America and 200–250V~, 0.2A max in other regions
Power consumption	Normal: 4.5W, Power saving mode: <0.5W
Operating temperature	0 to 40 C (32º to 104º F)
Operating humidity	10–90% maximum relative humidity, noncondensing
Storage humidity	5–95% maximum relative humidity, noncondensing
Electromagnetic emissions:	FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals:	UL Listed (UL 60950-1:2nd Ed.) /cUL (CSA C22.2 No.60950-1-07 2nd Ed.); CE LVD; TUV CB, TUV GS
Bandwidth	5 00Mbps
Data transfer rate	U p to 200M bps with real throughput greater than 80Mbps
Compatibility	Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible

Weight and Dimensions

Dimensions	114 x 55 x 32.5 mm (4.5 x 2.2 x 1.28 in.)
Weight	0.174 kg (0.38 lb)
