21
A
A. Supplementary Information
Technical Specifications
Feature Specification
Data and routing protocols IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx) IEEE 802.3ab
(1000BaseTx)
AC input 100–125V~, 0.2A max in North America and 200–250V~, 0.2A max in
other regions
Power consumption Normal: 4.5W, Power saving mode: <0.5W
Dimensions 114 x 55 x 32.5 mm (4.5 x 2.2 x 1.28 in.)
Weight 0.174 kg (0.38 lb)
Operating temperature 0 to 40 C (32º to 104º F)
Operating humidity 10–90% maximum relative humidity, noncondensing
Storage humidity 5–95% maximum relative humidity, noncondensing
Security encryption type 128-bit AES
MAC addresses 64: number of nodes that can be added to a single network
Bandwidth 500 Mbps
Compatibility Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible
Data transfer rate Up to 200 Mbps with real throughput greater than 80 Mbps
Frequency band: 2–80 Mbps
Modulation type: OFDM symbol modulation
Electromagnetic emissions: FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals: UL Listed (UL 60950-1:2nd Ed.) /cUL (CSA C22.2 No.60950-1-07 2nd
Ed.); CE LVD; TUV CB, TUV GS
