3
-
CONTROLS
AND
INSTRUMENTS
Rearward
controls
Storage
compartment
Located
below
the
operator's
seat,
this
compartment
is
used
to
store
various
objects.
Lock
and
unlock
the
storage
compartment
with
the
starter
key
.
NOTE:
for
the
canopy
version,
there
is
a
storage
compart-
ment
located
behind
the
operator's
seat.
SMIL19MEX0757BA
