3-CONTROLSANDINSTRUMENTS
Safetylocklever
WARNING
Unexpectedmachinemovement!
Whenyoumustleavetheoperator’sseat,al-
waysplacethesafetyleverintheLOCKEDpo-
sition.Ifthesafetyleverisunlockedandthe
controlleverismovedunexpectedly,aserious
accidentcouldresult.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1241A
Thesafetyleveroperatesontwopositions:
A.Lockedposition:whenthesafetylever(1)isinlocked
position(A),allthefunctionsaredisabled.
NOTICE:neverusethesafetylockleverasahand-
holdwhengetinoroutthemachine.
B.Unlockedposition:whenthesafetylever(1)isinun-
lockedposition(B),themachineisoperative.
SMIL16MEX2743AA1
Enginespeedcontrol
Theknob(1)isusedtoincreaseordecreasetherotation
speedofengine(RPM).
Seetherelevantdecallocateonthelefthandconsole.
Rotatetheknobclockwise(A)toincreaseengineRPM.
Rotatetheknobcounterclockwise(B)todecreaseengine
RPM.
NOTE:whenstoptheengine,rotatetheenginespeed
controlinlowidlepositionandturnthestarterkeyOFF .
SMIL16MEX2743AA1
3-16
