New Holland E37C - Protecting the Electronic and Electrical Systems During Battery Charging or Welding

6-MAINTENANCE
Protectingtheelectronicandelectricalsystemsduringbattery
chargingorwelding
DANGER
Improperoperationorserviceofthismachinecanresultinanaccident.
Anyunauthorizedmodicationsmadetothismachinecanhaveseriousconsequences.Consultan
authorizeddealeronchanges,additions,ormodicationsthatmayberequiredforthismachine.Do
notmakeanyunauthorizedmodications.
Failuretocomplywillresultindeathorseriousinjury.
D0030A
WARNING
Batteryacidcausesburns.Batteriescontainsulfuricacid.
Avoidcontactwithskin,eyesorclothing.Antidote(external):Flushwithwater.Antidote(eyes):ush
withwaterfor15minutesandseekmedicalattentionimmediately.Antidote(internal):Drinklarge
quantitiesofwaterormilk.Donotinducevomiting.Seekmedicalattentionimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0111A
Whenevercarryingoutaweldingoperationontheundercarriageorupper-structurecarriageasauthorizedbyNEW
HOLLANDCONSTRUCTIONandinaccordancewiththeirinstructions,disconnectthebatteries,disconnecttheal-
ternatorB+,D+terminalwires,andtheinstrumentclusterconnectorandconnecttheweldingapparatusgroundcable
tothecomponentonwhichtheweldingoperationistobeperformed.Neverconnecttheweldingapparatustothe
undercarriagewhenweldingontheupper-structure(orvice-versa).Neverconnecttheweldingapparatusgroundto
acomponentofthehydraulicsystem.
Toavoiddamagetotheelectronic/electricalsystems,
alwaysobservethefollowing:
•
Nevermakeorbreakanyofthechargingcircuitcon-
nections,includingthebatteryconnections,whenthe
engineisrunning.
•
Nevershortanyofthechargingcomponentstoground.
•
MakesuretosetthebatterydisconnectswitchtoOpo-
sition(OFFposition)inadvanceorcut-offtheconnec-
tionofthegroundcablewhenexecutingarcweldingto
themachine.
•
Alwaysdisconnectthenegativecablefromthebattery
whenchargingthebatteryinthemachinewithabattery
charger.
NOTICE:positiontheweldergroundclampasclosetothe
weldingareaaspossible.Ifweldingincloseproximityto
acomputermodule,thenthemoduleshouldberemoved
fromthemachine.Neverallowweldingcablestolayon,
nearoracrossanyelectricalwiringorelectroniccompo-
nentwhileweldingisinprogress.
NOTICE:ifweldingmustbeperformedontheunit,either
themachine,thebatterygroundcablemustbediscon-
nectedfromthemachinebattery.Theelectronicmonitor-
ingsystemandchargingsystemwillbedamagedifthisis
notdone.
6-16
