Newall C70 - Encoder

C70 Digital Readout System
Encoder
SETUP, Unit Information Mode, Machine Type, Encoder
NOTES
The Encoder settings
must match the actual
encoder in use, or the
C70 will not display
correctly.
Newall Measurement Systems Ltd 9
Encoder Type
There are three possible settings for each axis:
Spherosyn
Microsyn 10
Microsyn 5
• Press the Select Key next to the , or to cycle between the three settings for each axis.
Encoder Resolution
The Resolution settings available for each axis will depend on the encoder type, and also on the
setting.
Display Spherosyn Microsyn 10 Microsyn 5
mm in
1µm 0.001 0.00005 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2µm 0.002 0.0001 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5µm 0.005 0.0002 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10µm 0.01 0.0005 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20µm 0.02 0.001 . . . . . . . . . . . . . . . . . . . . . . . . .
50µm 0.05 0.002 . . . . . . . . . . . . . . . . . . . . . . . . .
• Press the Select Key next to the , or to cycle between the four available settings for
each axis.
