Newall dp1200 - Page 37

36
PCD / Bolt Hole Circle (Continued)
Mill Functions
Note: At this point you can use the keys to navigate back and forth through the menus.
To start the PCD / Bolt Hole Circle Routine;
Circle centre
150mm
diameter
X axis
Starting hole
Y axis
99.7mm
Datum
125.25mm
18º
starting
angle
(-196.580, -122.880)
-196.580
-122.880
Fig 1
Navigate through the sequence of holes by using keys.
