Setting Up The Unit
Setup Menu Navigation (continued)
8
Navigating Axis 4 Setup (Digital Linear)
Quick Navigation of Axis 4 Setup (Digital Linear)
Numeric Key Setup Function
1 Legend Setup
2 Encoder Setup
3 Reference Source Setup
4 Resolution Setup
7 Display Resolution Setup
8 Direction Setup
9 More Options
Press Key 9 for the options below
1 Radius / Diameter Setup
2 Signal Checking Setup
3 Zero Approach Setup
4 Error Compensation Setup
9 Back to Previous Options
The quick navigation feature for the setup of axis 4 digital linear is detailed below (where navigation
to the main axis setup menu is completed).
