38
Line Hole (Continued)
Mill Functions
To start the line hole circle routine;
-180.500
-200.000
Navigate through the sequence of holes by using keys.
180.5mm
200mm
Y axis
X axis
Datum
Starting point
350mm line
length
9 holes
20º
line
angle
Fig 2
