Lathe Functions
Teach Offsets (Continued)
45
Program Offsets
102.225
50.000
25.755
9.850
Measure the part using an accurate
gauge and enter this value.
Repeat this process for all tools required.
Note: Use the keys to navigate through the tools
Enter the tool dimensions one axis at a time.
Repeat this process for all tools required.
Once complete:
Note: Use the keys to navigate through the tools.
Enter the position value using the
numeric keys
of the required axis
