Figure 17-3B - BECKETT BURNER PARTS LIST
BECKETT BURNER PARTS LIST
ITEM NO.
PART NUMBER
NM50 2 NM50 3
DESCRIPTION
BECKETT NEWMAC
1 5877 D2090024 X X Burner Housing Assembly
2 3709 X X Air Shutter
3 3492 X X Air Band
4 3493 X X Escutcheon Plate
8 21844U D2060012 X X Pump Clean Cut A2EA - 6520
51843U X X Strainer & Gasket
10 21755U D2090065 X X Valve Coil (Suntec Part No. 3713824)
7
21877U D2090072 X X Valve Stem
51573 D2090058 Suntec Pump c/w Solenoid Valve
51843U Strainer & Gasket
21755U Valve Coil (Suntec Part No. 3713824)
Valve Stem (Includes 2 O Rings) (Suntec
Part No. 3773578)
Solenoid Valve Repair Kit (Suntec Part No.
991375)
9 21807 X X Valve cordset
11 2256 Pump Nozzle Port Fitting
12 5394 Connector Tube Assembly
13 21805U D2020012 X X PSC Drive Motor, 3450 RPM
14 2999U D2090056 X X Blower Wheel
16
7456U D2090069 X X Primary Relay, Honeywell R7184B
7457U D2090067 Primary Relay, Honeywell R7184P
17 5770 X X Junction Box Kit
18 51771U D2090064 X X Electronic Ignitor (14,000 Volt)
20 7006U D2010006 X X Cad Cell C554A1455B Honeywell
21 3384 X X 3-3/8U Static Plate
22 5153633BK D2090039 X X Blast Tube c/wWelded Flange AFG (7 7/8”)
D2110007 X Endcone, F4
D2110009 X Endcone, F6
24
D2090022 X X Electrode Assembly 8”
31517 D2110015 X X Ceramic Heat Shield
D2110016 X X Ceramic Heat Shield Holder
3416 D2080051 X X Flange Gasket
51770 D2090061 Field Controls AirBoot
5880 D2090044 X X Low Firing Rate Bafe
5941 X X Adjusting Plate Assy
D2100131 X Nozzle, Delavan 0.75 X 70oA
D2100128 X Nozzle, Delavan 0.85 X 70oA
D2100132 X X Nozzle, Delavan 1.00 X 70oA
D2100129 X Nozzle, Delavan 1.25 X 70oA
D2100133 X Nozzle, Delavan 1.35 X 70oA
D2100134 X Nozzle, Delavan 1.50 X 70oA
Note: Also approved with SR Burner – See General Instructions & Certication Label
