Newport Electronics P6000A - Figure 5-2 Connections with a Parallel BCD Printer Using Left-Hand Decimal Point

8
P6000A/P5000 Parallel BCD Parallel BCD Printer
To appro- BCD 1
priate level BCD 2
DIGIT 1
to print BCD 4
BLANK BCD 8
BCD 1 L18 BCD 10
DIGIT 1 BCD 2 U18 BCD 20
DIGIT 2
BCD 4 L17 BCD 40
BCD 8 U17 BCD 80
BCD 10 L16 BCD 100
DIGIT 2
BCD 20 U16 BCD 200
DIGIT 3
BCD 40 L15 BCD 400
BCD 80 U15 BCD 800
BCD 100 L14 BCD 1 k
DIGIT 3
BCD 200 U14 BCD 2 k
DIGIT 4
BCD 400 L13 BCD 4 k
BCD 800 U13 BCD 8 k
BCD 1 k L11 BCD 10 k
DIGIT 4
BCD 2 k U11 BCD 20 k
DIGIT 5
BCD 4 k L10 BCD 40 k
BCD 8 k U10 BCD 80 k
BCD 10 k L9 BCD 100 k
DIGIT 5
BCD 20 k U9 BCD 200 k
DIGIT 6
BCD 40 k L8 BCD 400 k
BCD 80 k U8 BCD 800 k
BCD 100 k L6 BCD 1 M
DIGIT 6
BCD 200 k U6 BCD 2 M
DIGIT 7
BCD 400 k L5 BCD 4 M
BCD 800 k U5 BCD 8 M
d.p. 1 U19 d.p. B1 Decimal point
d.p. 2 L12 d.p. B2 binary address
d.p. 4 U12 d.p. B4 (left-hand
decimal point)
Figure 5-2 Connections with a Parallel BCD Printer
Using Left-hand Decimal Point
