7.0 CALIBRATION
Be sure to use the four display digits during calibration as selected in
Section 4.2 .
NOTE: Calibration is possible without an input signal by setting FUNCTION to
TOTAL and then OFFSET to the appropriate display reading.
7.1 Voltage output (V01)
1. Attach a voltmeter (4 1/2 digit or more) with the negative lead to TB4-1 and the
positive lead to TB4-2 on the rear panel of the unit.
2. Set the voltmeter range to 10 V dc full scale.
3. Apply a signal to the input which displays the lower display reading (LD) and
adjust R8 (Z) to read the lower output voltage (LO) on the voltmeter.
4. Apply a signal to the input which displays the upper display reading (UD) and
adjust R7 (S) to read the upper output voltage (UO) on the voltmeter.
5. Repeat steps 3 and 4 above.
7.2 Current Output (I01)
1. Attach an ammeter (4 1/2 digit or more) with the negative lead to TB4-1 and
the positive lead to TB4-2 on the rear panel of the unit.
2. Set the ammeter range to 20 mA full scale.
3. Apply a signal to the input which displays the lower display reading (LD) and
adjust R8 (Z) to read the lower output current (LO) on the ammeter.
4. Apply a signal to the input which displays the upper display reading (UD) and
adjust R7 (S) to read the upper output current (UO) on the ammeter.
5. Repeat steps 3 and 4 above.
