4.1 Output Range Selection
Select one of the ranges from the Output Range Table (see Table 4-1). Then
install push-on jumpers as required.
4.2 Display Range Selection
Select one of the ranges from the Display Table (see Table 4-2), left 4
digits (4 MSD) or right 4 digits (4 LSD). Then install push-on jumpers as
required.
RANGE OUTPUT S1 S3
FULL-SCALE
RANGE
S4 GAIN WITH DEFAULT
SCALE & OFFSET
*V01 0-10 V ABE B 4 LSD A 1mV/count
I01 0-20 mA ABE A *4 MSD B 1mV/100 counts
I02 4-20 mA AB A *Default Setting
* Default Setting
Table 4-1 Output Ranges Table 4-2 Display Ranges
4.3 Span Range Selection
Using lower output (LO), upper output (UO), lower display (LD), and upper
display (UD), calculate the gain in counts/output.
(UD - LD)
counts/output =
(UO -LO)
Select one of the ranges from the Span Table (see Table 4-3). Then install
push-on jumpers as required.
