Peak 650 User's Guide Rev. A October 2000
Capability Expand
2-2
2-2 Switches
Switches on the CPU board are used to select options for different functions used. The switch-on or off is
to accommodate the variations of the following table.
Switch Setting Table (*: default setup)
S1 (*: Default setting)
1 2 3 4 CPU FSB / Memory
ON ON OFF OFF * Auto detect
OFF OFF ON ON 66MHZ / PC100 SDRAM
OFF OFF OFF ON 100MHZ / PC100 SDRAM
OFF OFF ON OFF 133MHZ / PC133 SDRAM
OFF OFF OFF OFF Reserve
SW2 (*: Default setting)
SW2 1 2345678910
RS232 (*)
OFF OFF OFF ON OFF ON OFF OFF OFF OFF
RS422
ON ON ON OFF ON OFF ON ON ON ON
RS485
ON ON OFF ON ON OFF OFF OFF OFF ON
SW1 (*: Default setting)
SW1/M-System Disable (*) C0000 C8000 D0000 D8000
1 OFF ON ON ON ON
2 X ON ON OFF OFF
3XONOFFONOFF
4 XXXXX
