2-3 Connectors
Jumper/Connector Define
J1: External speaker connector
Pin 1 Pin 2, 3 Pin4
Speaker signal GND VCC5
J2: Power supply type select:
Pin1-2 short AT power
Pin2-3 short ATX power
J4: 5VSB power cable connector
Pin 1 Pin 2 Pin3
5VSB GND ATX power supply S_ON”
Jp1: VCC5 power connector (for DOM)
Pin 1 Pin 2
VCC5 GND
Jp3: Keylock connector
Pin 1 Pin 3,5 Pin 4
VCC5 GND keylock signal
J13: Reset button
Pin 1-2 Reset
JP4: CMOS set up
Pin 1-2 Pin 2-3
Normal Clear CMOS
J9: Power On button (ATX)
Pin 1-2 Power on
J11: IDE LED connector
Pin 1 Pin 2
VCC5 IDE LED signal
