Peak 650 User's Guide Rev. A October 2000
Capability Expand
2-4
IR1: IR connector
Pin 1 Pin 2 Pin 3 Pin 4 Pin 5
VCC5 NC IR_RX GND IR_TX
J12: External keyboard connector
Pin 1 Pin 2 Pin 3 Pin 4 Pin 5
Keyboard CLK Keyboard DAT NC GND5 VCC5
JP2: I2C connector
Pin 1 Pin2
SMB DAT SMB CLK
J17: NEXCOM Reserved
Note
: For Model Peak 650VL and Peak 650M8, the Nexcom plug in Module EBK SCSI2 or EBK
SCSI160D cannot use Ad24 for IDSEL.
EBK SCSI 160D Jumper Setting
ON Board Active Terminal Resistor
Enable Disable
Channel A S1.1 OFF ON
Channel B S1.2 OFF ON
IDSEL Jumper
AD20 JP1.1, JP1.2 Short
AD24 JP1.2, JP1.3 Short
SCSI LED Jumper
LED+: JP2.1
Channel A
LED-: JP2.2
LED+: JP2.3Channel B
LED-: JP2.4
