DESIGN OF NE620T
Illustration 002: Product image of NE620T back/side view.
B
3
NE620T back/side view













BASIC DESIGN
21. Viewing head holding screw
22. Condenser centering screw (on both sides)
23. Condenser holding screw
24. Y-axis knob
25. X-axis knob
26. Right fine focusing knob
27. Limit knob (up-stop)
28. Mains in
29. Holding device for power cord
30. Power cord
31. Type plate with important information
32. USB interface
33. Carrying handle 2
Power Supply:
AC 100-240 V; 50/60 Hz
Specification of fuse:
250 V
