Nextar MA794 User Manual

38
Specifications
Audio Format MP3/WMA/WAV Size 43*84*8.3 mm
Photo Format JPEG/BMP weight ＜40g (without accessories)
Video Format MTV Frequency response 20Hz~20KHz
MP3 bit Rate 8Kbps–320Kbps Dynamic current ≤40mA (Play Mp3, backlight off)
WMA bit rate 5Kbps–320Kbps Power off current ≤0.30mA
S/N rate ≥85dB Storage condition Humidity <90%, Normal temperature
Dynamic range ≥80dB Working condition Humidity <85%,-10~40℃
Distortion <0.2% Power out 2*1mW(16 ohm load)
Battery 300mAh, up to 8 hours playback for music and 3 hours for video
EQ Normal/Pop/Rock/Classic/Jazz/Bass/Custom EQ
Support video format to
converter
AVI(*.avi), WMV(*.wmv, *.asf), MPEG1(*.mpg), QuickTime(*.mov, *.qt), MPEG2(*.vob), RealMedia(*.rm, *.rmvb,…),
MPEG4, 3GP(*.3gp)
