Installing the NI cDAQ-9178/9174
NI cDAQ-9178/9174 Dimensions
Figure 3 shows the dimensions of the NI cDAQ-9178/9174 chassis.
Figure 3. NI cDAQ-9178/9174 with Dimensions in Millimeters (Inches)
8
7654321
19.0 mm
(0.75 in.)
4.1 mm
(0.16 in.)
INPUT
9-30 V
15 W MAX
POWER READY ACTIVE
V
C
19.8 mm
(0.78 in.)
4321
INPUT
9-30 V
15 W MAX
POWER READY ACTIVE
V
C
TRIG 0
TRIG 1
NI cDAQ-9174
NI CompactDAQ
47.8 mm
(1.88 in.)
63.1 mm
(2.49 in.)
25.0 mm
(0.98 in.)
23.7 mm
(0.94 in.)
20.3 mm
(0.80 in.)
31.7 mm
(1.25 in.)
23.2 mm
(0.91 in.)
69.9 mm
(2.75 in.)
51.7 mm
(2.04 in.)
36.4 mm
(1.43 in.)
88.1 mm
(3.50 in.)
59.6 mm
(2.35 in.)
165.1 mm
(6.50 in.)
NI cDAQ-9178
NI CompactDAQ
53.8 mm
(2.12 in.)
254.0 mm
(10.00 in.)
159.5 mm
(6.28 in.)
44.1 mm
(1.74 in.)
44.1 mm
(1.74 in.)
58.9 mm
(2.32 in.)
