7 Slacken off 6 screws.
8 Remove the left/rear side
panel on the cooling mod-
ule.
Ground cable
9 Unscrew the ground cable.
10 Disconnect the com-
pressor cables.
Securing
plate
11 Remove the 4 locking
plates holding the com-
pressor.
55Chapter 7 | Component replacementF1245
